Universal Testing Machine

QM100SS

Product Features

● UTM for ultra-precise (pharmaceutical, food, cosmetics, paper, tissue)
● Compact size
● High speed Raw-Data measurement
● Skin tissue, injection needle, band, hydrogel
● Special Exclusive Grip
Inquiry List

 QM100SS is an ultra-precise micro-load test equipment optimized for measuring micro-loads such as

adhesion, probe-tech, release force, softness and cutting strength of food, pharmaceuticals, information and communication materials.

High-performance indicators have excellent reproducibility and precision of 0.05 m/sec high-speed measurement

and high resolution measurement data.  The gripping dedicated to small precision capacity is composed of adapters that are easy to attach

and exchange, and can be manufactured and used in various special forms depending on the material, size, and load of the sample.











Specifications

MODEL QM100SS QM100S QM100SE
Capacity 5, 10Kgf 5, 10, 20, 50, 100, 200Kgf 20, 50, 100, 200Kgf
Crosshead Speed 0.1 ~ 600mm/min
Availability Travel
(Non Grip)		 450mm 850mm
Operating Travel 350mm (Excluding Mini Shear Grip) 650mm (Excluding Film Grip)
Distance from
the Columns		 Ø120
Indicator LCD Graphic Display LCD Graphic Display 7" Color LCD Touch Screen
Raw Data 150 ~ 240p/sec 150 ~ 240p/sec 50 ~ 120p/sec
Load Resolution < 0.002% < 0.01% < 0.02%
Safety Device Emergency S/W, Stroke & Load Limit, UP/Down Limit, Auto & Return Set Memory, Data Output (RS232C Type)
Dimensions 450(W) x 375(D) x 906(H)mm 490(W) x 500(D) x 1290(H)mm
