Heating Kneader Machine

QM310S

Product Features

● Convenient color touch screen
● Independent temperature control 3 zone-4 point system
● Wide temperature range and large capacity cylinder
● Twin blade turn-lock system
● High power and speed servo system (Option)
● Highly precise torque sensor (Option)

This product is to manufacture the test specimen using synthetic resin, rubber and raw materials.

Equipped with high power servo motors and direct helical gears which allows easy and convenient operation,

detachable blade can be clean easily and prevent from contamination and the plastic stirring blade

and torque sensor can be install optionally to measure change in thermal characteristic

and intrinsic viscosity of polymer which could have speed up to 150rpm and sample mold of 150cc with torque 500N•m.











Specifications

MODEL QM310S-T (Torque sensor type) QM310S (General type)
Mixer Blades Twin-Cryovac Blade (Detachable) Twin-Cryovac Blade (Detachable)
Temp. Range Max. 350℃ (recommend 80%) Max. 350℃ (recommend 80%)
Temp. Controller Digital P.I.D Controller Digital P.I.D Controller
Speed Range 1~150rpm/min 1~150rpm/min
Capacity Max. 150cc (recommend : 90cc) Max. 150cc (recommend : 90cc)
Mixing Bowl 2 Step (Separated Type) 2 Step (Separated Type)
Torque Max. 500N•m Max. 500N•m
Torque System Torque sensor : Digital Display -
Software (Q-Pro 5.0) Window 10, Parameter : Torque, Time, Temp -
