Extensometer
QM100E
Product Features
● Select Face Jaw according to material
● Push Lock-Holder Grip (Easy Sample Mounted)
● Installation of high-definition optical encoders
● Measurement of high elongation super long axis elongation (Min.10mm to Max.800mm)
● Measurement of low elasticity & faisson ratio with special strain gauge (Option)
● Push Lock-Holder Grip (Easy Sample Mounted)
● Installation of high-definition optical encoders
● Measurement of high elongation super long axis elongation (Min.10mm to Max.800mm)
● Measurement of low elasticity & faisson ratio with special strain gauge (Option)
It is a high-precision extensometer that minimizes the friction resistance of the grip when measuring the elongation of the test piece
by applying an optical isolator-type digital encoder and a high-precision low-resistance special bearing.
It is possible to adjust the bite force of other grips on the material, and it is convenient to remove/attach the elongation system
and move the measurement test with a mobile slider.
Specifications
| MODEL | QM100E | ||||
|---|---|---|---|---|---|
| Encoder | Digital Optical Encorder | ||||
| Resolution | ≤ ± 0.01mm | ||||
| Stroke Range | 1000mm | ||||
| Accuracy | ± 0.01mm at 300mm | ||||
| Dimensions | 160(W) x 260(D) x 1340(H)mm | ||||
