The QM100SH model is an equipment for measuring the wet tensile strength of tissues and tissue products,
and is an equipment for automatically wetting tissues and tissue products immersed in water according
to the length of the sample and then measuring the strength through constant speed stretching.
The tensile test may be measured automatically after fixing the regulated sample with an automatic air grip
in the horizontal method specified in the standard KS M ISO12625-5, and then dipping and maintaining the sample.
Specifications
| MODEL | QM100ST | ||||
|---|---|---|---|---|---|
| Capacity | Max. 10Kgf | ||||
| Stroke Range | Max. 250mm | ||||
| Speed Range | 0.1 ~ 600mm/min | ||||
| Soak Distance | Min. 6mm (Sample 50mm 기준) | ||||
| Safety Device | Emergency S/W, Stroke & Load Limit, UP/Down Limit, Auto & Return Set Memory, Data Output (RS232C Type) | ||||
| Dimensions | 600(W) x 480(D) x 432(H)mm | ||||
