The QM100SH model is an equipment for measuring the adhesive force of tape and adhesives, and is a high-speed peeling test equipment for automatically measuring
and analyzing changes in the adhesive force of samples through high-speed peeling.
A one-touch detachable grip adapter for measuring various test methods specified in the international standard PSTC, ASTM, TLMI, FINAT and TAPPI,
and a wide speed range of 100 to 40,000 mm/min, as well as a load range of up to 200 N.
The Quatro-3.0 Digital Servo Controller provides accurate and uniform measurement reproducibility when analyzing high-precision resolution
and displacement characteristics optimized for high-speed peeling tests and measuring 180Pe Peel, T-Peel, Mandrel Holding Power.
Specifications
| MODEL | QM100SH | ||||
|---|---|---|---|---|---|
| Load Cell | ㅁ6Kgf ㅁ 10Kgf ㅁ 25Kgf ㅁ30Kgf | ||||
| Force Range | Max. 200N | ||||
| Stroke Range | Max. 450mm | ||||
| Speed Range | 100 ~ 40,000mm/min | ||||
| Safety Device | Emergency S/W, Stroke & Load Limit, UP/Down Limit, Auto & Return Set Memory, Data Output (RS232C Type) | ||||
| Dimensions | 1000(W) x 480(D) x 580(H)mm | ||||
| Standard | ASTM D 3330, TLMI L-IA1 and L-IA2, PSTC-1, 3, and 4, and FINAT FTM 1, 2, 3, and 4 | ||||
