Automatic Coater

QM1200

Product Features

● Auto-go-back system after each test
● Test method Saving option
● Changeable bar coater adapter
● Adjustable pressuring the load accords to the viscosity
● Fixed test specimen and vacuum plate to emit the solvent (Option)
● For Heating only purpose (Option)

Inquiry List

Description
Specification
Video
Association

This product equipped with various bar coaters and applicators to perform constant thickness of paint coating on the test-specimen.

■ Standard : KS T 1028,T 1056

| Accessories For QM1200 (Option)

| Bar-Coater Table

Specifications

MODEL	QM1200	QM1200S	QM1200S-대형
Motor	BLDC Motor	Servo Motor & Ballscrew & Dual LM Rail System	Servo Motor & Ballscrew & Dual LM Rail System
Display	LED Display	7" Color LCD Touch Screen Display	7" Color LCD Touch Screen Display
Speed Range	20 ~ 100mm/sec	1 ~ 1200mm/min (주문제작)	1 ~ 1200mm/min (주문제작)
Bar Coater Holder	1 System	1 System	1 System
Plate Size	300 x 490mm (Themal Glass)	270 x 350mm (AL&Themal Glass)	320 x 500mm (AL&Themal Glass)
Standard	KS T 1028,T 1056	KS T 1028,T 1056	KS T 1028,T 1056
Dimensions	700(W) x 520(D) x 370(H)mm	670(W) x 530(D) x 410(H)mm	770(W) x 625(D) x 410(H)mm
Function	Speed & Stroke Memory (Memory 1, 2)	SV/PV (Stroke, Counter), Method memory, Origin Zero	SV/PV (Stroke, Counter), Method memory, Origin Zero
Option	Vaccum-Plate, Heat-Plate	Speed, Barcoater-Rotator, Vaccum-Plate, Heat-Plate	Speed, Barcoater-Rotator, Vaccum-Plate, Heat-Plate
